Basic robot workstation
Varianty: 1600x800 stationary
The Basic Robot Workstation from item Industrietechnik GmbH serves as a compact base frame for working with robots. Thanks to the item Groove Plate, the work surface can be used in a variety of ways. The robot and other components can be positioned individually. The lockable base cabinet provides sufficient space for the electrical equipment. It is stowed away safely and protected from dust. Cables can be routed to the robot arm through a brush strip above the two doors.
Note: Depending on the scaling of the solution, operating mode and robot model, the stability and design must be checked. On request, item will be happy to help you customise this application to meet the individual requirements of your project.
Hlavné body
Notification
Note: Depending on the scaling of the solution, operating mode and robot model, the stability and design must be checked. On request, item will be happy to help you adapt this application to the individual requirements of your project.
Technical details
Robot connection with item robot mounting plates for various robot manufacturers and models
Steplessly height-adjustable feet for a stable stand
Base cabinet with suspension for the control unit, battery, etc.
Work surface with continuous grooves
Integrated base cabinet with two doors
Cable routing to the robot through brush strips integrated into the work surface
